| Standards | ISO 7241-1 A |
| Interchangeability | Stucchi: BIR Series Faster: ANV Series |
| Occlusion | Poppet valve |
| Coupling | Radial balls |
| Materials | Galvanized steel Zn-Fe (Cr III) |
| Standard gaskets | NBR (on request FKM - EPDM) |
| Available threads | BSP DIN 3852-2-X (on request NPT - RC) |
| Operating temperature | -25 °C +100 °C |
| Connection under pressure | Not permitted |
| Supplier code | ISO size | Connection | PN ([bar]) | QN ([l/min]) |
|---|---|---|---|---|
| label PAV1.0606.002 | 6.3 | 1/4" | 350 | 12 |
| label PAV1.2019.002 | 19 | 3/4" | 250 | 106 |
| label PAV1.5051.002 | 50 | 2" | 160 | 757 |
| label PAV1.1313.002 | 12.5 | 1/2" | 250 | 45 |
| label PAV1.3939.002 | 40 | 1"1/2 | 190 | 379 |
| label PAV1.2525.002 | 25 | 1" | 200 | 189 |
| label PAV1.1010.002 | 10 | 3/8" | 350 | 23 |
| label PAV1.3031.002 | 31,5 | 1"1/4 | 200 | 288 |
