| PE | Operating pressure at 20 °C |
| PS | Bursting pressure at 20 °C |
| R | Minimum bending radius |
| Operating temperature | Max 60 °C |
| Colour | Blue |
| Supplier code | Pack ([m]) | Dimension | Model | ø-i ([mm]) | PE ([bar]) | PS ([bar]) | R ([mm]) | Width ([mm]) |
|---|---|---|---|---|---|---|---|---|
| label PV 6x4 | 50 | 6x4 | PV | 4 | 40 | 140 | 50 | 1,1 |
| label PV 8x6 | 50 | 8x6 | PV | 6 | 35 | 122 | 60 | 1,1 |
| label PV 10x8 | 50 | 10x8 | PV | 8 | 35 | 122 | 65 | 1,1 |
| label PV 12x10 | 50 | 12x10 | PV | 10 | 28 | 98 | 80 | 1,25 |
| label PV 15x12,5 | 50 | 15x12,5 | PV | 12,5 | 28 | 98 | 100 | 1,35 |
