| Operating pressure | 4,5 bar |
| Power supply | 24 V DC |
| Material | Anodised aluminium body |
| Operating temperature | 0 ÷ 45 °C |
| Exhaust | Built-in silencer |
| Other features | - Built-in suction fiter - Solenoid suction valve NC - NO - Solenoid blowing valve (solo NC) - Electronic vacuum switch (VS-T) |
| Supplier code | P port | V port | Camozzi part number | Consumption ([Nl/min]) | Vacuum level ([%]) | Nozzle ø ([mm]) | Suction flow-rate ([Nl/min]) | Valve |
|---|---|---|---|---|---|---|---|---|
| label SCPM 05 NC A | M5 | M5 | VEM-05C2-VE | 13 | 85 | 0,5 | 6 | NC |
| label SCPM 07 NC A | M5 | M5 | VEM-07C2-VE | 21 | 85 | 0,7 | 12 | NC |
| label SCPM 10 NC A | M5 | M5 | VEM-10C2-VE | 46 | 85 | 1,0 | 23 | NC |
| label SCPM 05 NO A | M5 | M5 | VEM-05A2-VE | 13 | 85 | 0,5 | 6 | NO |
| label SCPM 07 NO A | M5 | M5 | VEM-07A2-VE | 21 | 85 | 0,7 | 12 | NO |
| label SCPM 10 NO A | M5 | M5 | VEM-10A2-VE | 46 | 85 | 1,0 | 23 | NO |
