| Operating pressure | 5 bar |
| Material | Aluminium body and nozzles; NBR seals and butterfly valves |
| Operating temperature | 0 ÷ 50 °C |
| Exhaust | Built-in through type silence |
| Additional functions on request | - Double solenoid valve for suction(NC/NO) and Blowing (only NC) 24V DC - Safety check and exhaust valve (AS) - Digital vacuum switch (VD) |
| Supplier code | P port | V port | S port | Consumption ([Nl/min]) | Vacuum level ([%]) | Suction flow-rate ([Nl/min]) | Silencer | Size |
|---|---|---|---|---|---|---|---|---|
| label SEM 25 SDA | 393 | 1/2" | 1/2" | 101 | 85 | 393 | Assiale | 25 |
| label SEM 50 SDA | 704 | 3/4" | 3/4" | 197 | 85 | 704 | Assiale | 50 |
| label SEM 100 SDA | 976 | 1" | 3/4" | 376 | 85 | 976 | Assiale | 100 |
| label SEM 150 SDA | 1433 | 1" | 3/4" | 590 | 85 | 1290 | Assiale | 150 |
| label SEM 300 SDA | 3110 | 3/4" | 3/4" | 935 | 85 | 2370 | Assiale | 300 |
| label SEM 25 SDS | 332 | 1/2" | 3/4" | 101 | 85 | 332 | Laterale | 25 |
| label SEM 50 SDS | 642 | 3/4" | 3/4" | 197 | 85 | 642 | Laterale | 50 |
| label SEM 100 SDS | 909 | 1" | 3/4" | 376 | 85 | 909 | Laterale | 100 |
| label SEM 150 SDS | 1233 | 1" | 3/4" | 590 | 85 | 1190 | Laterale | 150 |
Contact us without obligation by filling in our form, our experts are at your disposal.
